# AltairScan™ series
Smart Flash Laser 3D Scanner AltairScan™
AltairScan can extract hole center coordinates and diameter at an instant, with an accuracy up to 0.02mm, certificated by National Institute of Metrology.
Features
- Hole flash capture technology.
- Dynamic scanning technology.
- Fine detail scan.
- Ultra high accuracy.
- Blue laser.
- Wireless.
Application Areas
Aerospace
- Rapid prototyping
- MRO & Damage assessment
- Aerodynamics & Stress Analysis
- Parts inspection and Adjustment
Automotive
- Competitive Analysis
- Car Modification
- Custom-made of Inner Decorations
- Automobile Modeling
- Quality Control & Measure of Accessories
- Simulation & Finite Element Analysis (FEA)
Die & Mould
- Virtual Assembly
- Reverse Engineering
- Quality Control & Inspection
- Wear Analysis & Maintenance
- Fixture Design & Adjustment
New Energy
- Hole assembly.
- Pre-processing component evaluation.
- Component to CAD inspection.
- Supplier quality control.
- Tool/robot path programming.
Other
- Education & Scientific Research
- Medical Heathcare
- Cultural Relic & Furnishings
- Industrial Design
- Reverse Design
- VR/AR
Specification
| Model | AltairScan™ | AltairScan Elite™ |
|---|---|---|
| MEASUREMENT RATE | 205,000 measurements/s | 480,000 measurements/s |
| SCANNING AREA | 275 × 250 mm | |
| BLUE LASER LIGHT SOURCE | 6 laser lines (+ extra 1 line) | 14 laser lines (+ extra 1 line) |
| LASER CLASS | CLASS 2 （eye-safe） | |
| RESOLUTION | 0.05 mm | 0.03 mm |
| ACCURACY | Up to 0.03 mm | Up to 0.02 mm |
| VOLUMETRIC ACCURACY | 0.03 + 0.06 mm/m | 0.02 + 0.06 mm/m |
| VOLUMETRIC ACCURACY (combined with Photshot) | 0.03 + 0.025 mm/m | 0.02 + 0.025 mm/m |
| HOLE ACCURACY | Up to 0.03mm | |
| HOLE VOLUMETRIC ACCURACY | 0.03+0.06 mm/m | |
| HOLE VOLUMETRIC ACCURACY (combined with Photshot) | 0.03+0.25 mm/m | |
| STAND-OFF DISTANCE | 300 mm | |
| DEPTH OF FIELD | 250 mm | |
